50 Ton Rated
50 Ton Rated
2-Way Split
2-Way Split
Safe & Efficient Log Stop Design
Safe & Efficient Log Stop Design
Made In Canada
Made In Canada
5-20 Second Cycle Time
5-20 Second Cycle Time

Split Wood Twice as Fast – No Waiting Between Cycles

Less time, less effort, more wood. Built for serious homeowners and pros.

6206

$8,800.00

A great attachment for a full-size skid steer, or mini skid looking to process large +48” gnarly logs. Whether you’re splitting your own large rounds, or splitting unwanted arborist drop offs, this is the ideal attachment. The splitting zone is located directly in front of the cab, so visibility is great. You won’t have a sore neck straining to see what’s going on with this setup. An overall heavy-duty design includes 3/8” thick plate bumper and hose safety to keep things looking good for this rough application. Don’t have a skidsteer? No problem, we make one for excavators too the SPLIT-FIRE 6209

The 6206 is rated for 50 tons with an average cycle time of 4-15 seconds, depending on auxiliary flow and pressure. Designed with a 12” standoff to improve splitting both in the horizontal and vertical orientation, all it takes is a fine hand on the controls to split those large dangerous rounds. Split those large logs into manageable chunks that can either be used for boiler wood, or further split down into quality firewood.

2–5 Year Warranty

BUILD & PRICE

OPTIONS

10 Weeks Build Time

SEE IT IN ACTION

MACHINE SPECS

Frame
10" x 10" steel tube
Log Capacity
30" - 72" diameter
Tonnage
50 tons @ 3500 psi
Total Cycle Time
13.412 x (30/GPM)
Power Source
Skid Steer | Includes 100” of hose
Pump
Skid Steer
Reservoir
Skid Steer
Stroke Length
30”
Quick Connects
Optional
Overall Width
102.5"
Overall Length
46.5”
Overall Height
19.5”
Weight
1825 lbs
Bed Height
N/A
Knife Height
20”
Cylinder Size
6” x 30"
Hydraulic Flow
20 GPM - 75 GPM
Min. Skid Steer Operating Cap
2400lbs
6206 technical drawing
